This high-end commercial display terminal is designed with an industrial-grade structural concept, featuring a seamless frame and a slim, lightweight body for easy installation and maintenance. Its unique heat dissipation technology allows for 24/7 operation. Equipped with an IPS high-definition LCD display panel, it delivers stunning visuals with vibrant colors and high brightness, supporting up to 1080P video and image decoding. Powered by an intelligent Android operating system, it comes with pre-installed front-end information publishing software and supports third-party software installation, catering to diverse usage needs. Widely favored across industries such as government, education, finance, transportation, hospitality, retail, exhibitions, healthcare, and more, this device combines aesthetics, high-definition capabilities, explosion resistance, user-friendliness, commercial-grade performance, and intelligence, making it a top choice for professionals seeking a versatile and advanced commercial display solution.
Panel | LCD Size | 32 inch | 43 inch | 49 inch | 55 inch |
Resolution | 1920*1080 / 3840*2160(Option) | ||||
Display Area(H x V)mm | 699×393.2 | 941*529 | 1096*616 | 1209.6*680.4 | |
Aspect Ratio | 16:9 | ||||
Brightness (cd/m2 ) | 350 | ||||
Colour | 16.7M(8-bit) | ||||
Viewing Angle | 178° | ||||
Contrast Ratio | 1200:1 | ||||
LED Type | E-LED | ||||
Audio | Speaker Type | Stereo 2×5W 8Ω | |||
AV I/O | Video | HDMI*1 | |||
Audio | Audio Socket(3.5mm)*1 | ||||
Power | Power supply | AC110~240V (50Hz~60Hz) | |||
Power consumption | 45W | 55W | 65W | 85W | |
Mechanical
| Unit Size (W*H*D mm) | 739.6*433.8*63.8 | 981.6*569.6*64 | 1136.4*658.7*70 | 1250*720.4*70 |
Package Size（W*H*D mm） | 800*500*130 | 1060*675*140 | 1240*790*150 | 1350*865*165 | |
Net Weight (KG) | 10 | 17 | 23.6 | 30 | |
Gross Weight (KG) | 12 | 21 | 27 | 35 | |
Environmental | Operating Temperature | 0℃~55℃ | |||
Storage Temperature | ‐5℃~60℃ | ||||
Operating Humidity | 10%RH~90%RH | ||||
Storage Humidity | 10%RH~90%RH | ||||
Operation System Android (Default) or Windows (Option) | CPU | Quad Core – A55 1.5GHz | |||
GPU | ARM G52 | ||||
RAM | 2G(4G option) | ||||
ROM | 16GB(8GB,32GB,64GB option) | ||||
USB | USB2.0 HOST (x2) ,TF (x1) | ||||
LAN | 10/100M Ethernet (Network Version Only) | ||||
WIFI | 802.11b/g/n/ac (Network Version Only) | ||||
OS | Android11 | ||||
Touch IR(Default) Or PCAP (option) | Touch Technology | IR | |||
Touch points | 20 | ||||
Protect glass | 3mm | ||||
Response time | 8ms | ||||
Accuracy | ±2mm | ||||
Accessories | Include | Scheduling Software, Wall Mount,Remote Control, Key, WIFI Stick,User Manual | |||
Option | Network Upgrade, Floor Stand/Trolley, Ceiling Mount, Table Stand | ||||
Warranty | Warranty period | 1year(Default),2 or 3years Option | |||
Technical support | Lifetime | ||||
Specification
切换内容
✔ High-Quality Screen: Immerse yourself in a world of vibrant visuals with our JPOK Display, featuring an explosion-proof glass screen that guarantees durability and safety. With its industrial high-performance screen, enjoy unparalleled image clarity, brightness, and stability, ensuring a viewing experience like no other. Upgrade to 4K for crisp, colorful images that leap off the screen.
✔ Built-In Operating System (OS): Seamlessly manage content files and control presentations with our customized built-in operating system. Tailor the display experience to suit your customers’ interests, ensuring a seamless and enjoyable interaction.
✔ Easy Data Control: Take charge effortlessly with two operating options – remote control via wireless connection (WiFi, 3G/4G/5G, or Bluetooth) or simple USB Plug and Play functionality.
✔ Storage: With the demand for high-quality media files increasing, JPOK Display offers ample storage capacity, both internally (ranging from 1GB to 8GB) and externally via USB, HDD, and SSD, ensuring you never run out of space for your content.
✔ IPS Commercial Grade Panel: Say goodbye to viewing angle limitations and color reproduction issues with our IPS (In-plane switching) commercial-grade panel, designed to deliver superior performance compared to TFT screens.
✔ 24/7 Continuous Usage: Designed for uninterrupted performance, JPOK Display can operate continuously for long hours and days, making it perfect for commercial use in any setting
✔ Centralized Terminal Devices Management: Take control with our cloud-based content management system, allowing real-time control and insights into smart digital players, empowering remote management of content, display schedules, and more.
✔ Eco-Friendly Power Timer: Save energy and reduce costs with our eco-friendly power timer feature, allowing you to schedule hourly, daily, or weekly power on and off times. Enjoy efficient energy consumption and the convenience of standby mode during periods of inactivity.
✔ Multiple Versatile I/O Ports: Experience seamless connectivity with a wide range of audio and video inputs and outputs, including SD card, USB Flash, HDMI, VGA, DVI, USB, and RJ45 ports, ensuring fast dynamic picture quality without delays or frame loss.
✔ Multiple Configuration: Customize your JPOK Display with multiple level options, offering processors from Dual-Core to Octa-Core and OS versions from Android 7.1 to Android 12. Choose your preferred OS between Android, Windows, Linux, or standalone OS for a personalized experience.
✔ Lifetime Technical Support: Enjoy peace of mind with our lifetime technical support, ensuring assistance throughout the warranty period and beyond. Our dedicated team is here to provide free technical support for any inquiries or issues you may encounter.
✔ Warranty: Rest assured with our full one-year commercial warranty (Extended warranty optional) covering defects resulting from faulty parts, materials, or manufacturing. JPOK Display is built to withstand 24/7 use in public spaces, ensuring long-lasting performance and customer satisfaction.
